Tektronix Mso4104B Mixed Signal Oscilloscope; Digital Phosphor, 1Ghz, 5Gs/S, 20
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
| Service & Purchase | Price |
|---|---|
| Equipment repair to manufacturers specifications. | Inquire for pricing |
| Standard calibration to manufacturers specifications. | Inquire for pricing |
| Calibration including pre and post calibration data. | Inquire for pricing |
| Calibration with 17025 accreditation. | Inquire for pricing |
Description
The Tektronix MSO4104B Mixed Signal Oscilloscope is a powerful and versatile tool for engineers and technicians. With a bandwidth of 1Ghz and a sampling rate of 5Gs/S, it is capable of capturing and analyzing complex waveforms accurately and efficiently. The digital phosphor technology provides a clear and detailed display, allowing users to easily identify and troubleshoot signal anomalies. With 20M record length, it can capture long-duration signals and high-speed events without missing any important details. Whether in the field or in the lab, the Tektronix MSO4104B is a reliable and indispensable instrument for any electronics professional.
Specifications
– Model: Tektronix Mso4104B
– Type: Mixed Signal Oscilloscope
– Technology: Digital Phosphor
– Bandwidth: 1Ghz
– Sample Rate: 5Gs/S
– Number of Channels: 4
– Input Impedance: 1 MΩ
– Maximum Input Voltage: 300 Vrms
– Vertical Resolution: 8-bit
– Display Type: Color TFT
– Display Size: 10.4 inches
– Waveform Capture Rate: 50,000 wfms/s
– Record Length: 10 Mpoints
– Horizontal Scale Range: 500 ps/div to 1000 s/div
– Vertical Scale Range: 1 mV/div to 10 V/div
– Trigger Types: Edge, Pulse Width, Runt, Timeout, Video, Pattern, Delay
– Connectivity: USB, Ethernet, GPIB, VGA, AUX OUT
– Power Supply: 100-240 VAC, 50/60 Hz
– Weight: 14.3 lbs (6.5 kg)
– Dimensions: 13.4 x 16.2 x 5.4 inches (340 x 411 x 136 mm)
Tektronix Mso4104B is also available with the following specs and model:
- Oscilloscope Mixed Signal Digital 1GHz 5 GS/S Analog Chs 4 / Dig Chs 16
